Autodesk AutoCAD Electrical 2027 for Windows

Professional Electrical Design & Control System Software

Autodesk AutoCAD Electrical 2027 is professional electrical design software for engineers, control-system designers, automation professionals, technicians, and panel designers. Built on the AutoCAD platform, the Electrical toolset adds specialized features for creating, modifying, and documenting electrical control systems.

Key Features

• 65,000+ intelligent electrical symbols
• Professional electrical schematic design tools
• Automatic wire numbering and component tagging
• Circuit design and editing tools
• Electrical panel layout creation
• PLC I/O drawing tools
• Terminal strip design and management
• Automatic electrical reports and documentation
• Project-wide drawing management
• Component and catalog database tools
• Manufacturer catalog data support
• DWG file compatibility
• Advanced AutoCAD drafting and editing tools

AutoCAD Electrical 2027 Highlights

ECLASS Data Import: Import compatible manufacturer catalog data, footprints, and supported 3D-part information into the catalog database.

Terminal Strip Export: Export terminal-strip information for supported manufacturer applications.

Improved Reliability: Enhancements across wire numbering, reports, catalogs, terminal strips, panel workflows, and PDF plotting.

Ideal For

Electrical Engineers, Control Engineers, Automation Professionals, Industrial Designers, Panel Designers, Electrical Contractors, Engineering Students, and Manufacturing Projects.

System Requirements

• Platform: Windows 64-bit
• Recommended OS: Windows 11
• Memory: 16 GB RAM minimum, 32 GB recommended
• Display: 1920 × 1080 or higher
• Graphics: DirectX-compatible GPU

Product Details

• Product: Autodesk AutoCAD Electrical
• Version: 2027
• Platform: Windows
• Delivery: Digital Download
• File Type: Digital Software

Important: This is a digital product. No physical item will be shipped.
